VLAN Global Settings Description
802.1Q Tag Aware Mode Enable - Under this mode, the switch will check the content of
every received packets. For 802.1Q tagged packets, the tagged
VID on the packet is used to look up the VLAN group table and
find the group whose VID matches the packet tagged VID.
Disable - Under this mode, the switch does not check the contents
of the received packets. The default VLAN group indexed by the
ingress port is used directly for further VLAN operation.
Ingress Member Filtering Mode Enable - Drop packet if the ingress port is not the member port of
the VLAN group
Disable - No ingress member filtering is applied
Select [4] VLAN Group Member Settings to configure member ports for VLAN groups.
Input Description
Groups Specify group list to be configured. More than one group can be configured at the same
time. Examples:
123 - Group 1, Group 2, Group 3
1 2 3 - Group 1, Group 2, Group 3
1,2,3 - Group 1, Group 2, Group 3
Ports Enter port list for the selected groups
Examples:
123 - Port 1, Port 2, Port 3
1 2 3 - Port 1, Port 2, Port 3
1,2,3 - Port 1, Port 2, Port 3
Select [5] VLAN Group VID Settings to configure VLAN ID for VLAN groups.
VID Setting Description
Groups Select group list to be configured.
VLAN ID Enter VLAN ID for the selected groups
Valid values : 1 - 4095
