Blown Fuse
The rear panel of the receiver includes a fast-blow
fuse rated for 8 amps. If this fuse has blown, the
system will not operate.
Unscrew the cap and replace
the fuse. If you replace the
fuse, but it blows again,
check the receiver to ensure
that it is clear of debris and
the connectors are tight. Do
not replace the fuse with a
larger amperage fuse.
Insufficient Power
With the vehicle powered up and the receiver turned
on, power at the receiver must measure at least
10 VDC for the TracVision system to work properly.
Check the receiver’s power connection and ensure
that it is wired to a dedicated circuit. If other devices
are wired to the same circuit, these additional loads
might drain power away from the receiver.
54-0376
Troubleshooting
10.5
10-3 Causes and Solutions to Common
Problems
There are a number of common issues that can affect
the signal reception quality or the operation of the
TracVision system. The following sections identify
these issues and provide potential solutions.
Receiver Power Switch Turned Off
Your TracVision receiver’s power switch (see below)
must remain on for the system to work. If the system
is entirely non-functional, check the switch to ensure
that it is turned on. The VOLTAGE status light
illuminates green when turned on.
Power Switch
,
POWER (10-16V DC)
MAINTENANCE PORTS
USB RS232
FUSE (8A)
Fuse
