A.12 tracvision mobile receiver user’s guide, Destacker (dual-output), Standard receiver #1 – KVH Industries antenna system User Manual
Page 107: Standard receiver #2, This receiver controls satellite selection, Stacked signal stacked signal, Unstacked signals
C AU T I O N
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) This device must not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
S -VIDEO
VIDEO AUDIO L AUDIO R
RF
REMOTE
INPUT
DIGITAL
AUDIO
OUT
TO
110W/HD
CONVERTER
TO KVH
ANTENNA
POWER (10-16V DC)
MAINTENANCE PORTS
USB
RS232
FUSE (8A)
Tested to comply
with FCC Standards
To Antenna
Mobile Receiver
Splitter
Stacked Signal
Stacked
Signal
Destacker
(Dual-output)
SATELLITE IN
OUT TO TV
TV ANT/CABLE IN
AUDIO
VIDEO
S-VIDEO
PHONE JACK
R
L
SATELLITE IN
Standard Receiver #1
SATELLITE IN
OUT TO TV
TV ANT/CABLE IN
AUDIO
VIDEO
S-VIDEO
PHONE JACK
R
L
SATELLITE IN
Standard Receiver #2
Unstacked
Signals
SECONDARY
PRIMARY
ANTENNA
INPUT
To RECEIVER
2
1
To TV
54-0376
A.12
TracVision Mobile Receiver User’s Guide
Wiring Diagram for One TracVision Mobile Receiver and Two Standard Home Receivers
This receiver
controls satellite
selection
