System Overview
Your TracVision system is a state-of-the-art, actively
stabilized antenna system that delivers live satellite
TV to your mobile audio/video entertainment
system.
Receiver
The receiver decodes
satellite TV signals
from the antenna unit
and sends the signals
to the audio/video system. It also powers and
controls the TracVision antenna.
Remote Control
The wireless RF/IR remote control
allows you to control all receiver
functions. The remote does not need
to be pointed directly at the receiver
for the signal to be received.
RF Converter
The RF converter receives
RF commands from the
remote control, converts
them to digital signals, and
sends them to the receiver
for processing.
54-0376
1.4
TracVision Mobile Receiver User’s Guide
Video Display(s)
To TracVision Antenna
Purchased Separately
Receiver
Remote Control
CH
VO
L
DVD
VCR
AUX
TV
SA
T
HRMC-9
GUIDE
MENU
INFO
CLEAR
TURBO
FA
V
SELECT
MUTE
CH
PREV
PR
OG
SEARCH
AU
DIO
VID
EO
1
2
3
4
5
6
7
8
9
0
INP
UT
REW
PLA
Y
FF
REC
ST
OP
PA
USE
P
A
G
E
ONELIN
E G
U
ID
E
PW
R
DIRECT
OR
RF Converter
Input Power (+12 VDC)
TracVision System Diagram (Typical Installation)
