KID KART PARTS MANUAL PAGE 1.4 MAY 2007 A.R.T. GROUP
INSIDE BACK / SHELL
XPRS0X04
ITEM NUMBER DESCRIPTION QTY
8 9612000920 MACH SCREW 1/4-20 x 1-1/4 FHS ANS 2
9 9650701012 NYLOCK NUT, LOW 1/4-20 ZPS 2
10 102674 BACK SHELL - INNER BOTTOM 1
1-12(A) 103625 BACK SHELL - STANDARD
1-12(B) 103626 BACK SHELL - EXTENDED
102676 VELCRO ® KIT - STANDARD 1
102719 VELCRO ® KIT - EXTENDED 1
ITEM NUMBER DESCRIPTION QTY
1 102673 BACK SHELL - MAIN 1
2 226347 SMS #10-16 x 1-1/4 FHP, SELF-TAP ZPS 2
3 9555201301 MACH SCREW 1/4-20 x 5/8 SBHCS ANS 8
4 9683120104 T-NUT 1/4-20 x .25 SLOT-BASE ZPS 4
5A 102675 BACK SHELL - INNER TOP, STANDARD 1
5B 102682 BACK SHELL - INNER TOP, EXTENDED 1
6 9681120106 T-NUT 1/4-20 x 3/8 ROUND ZPS 4
7 262110-QU WASHER 1/4” FLAT THIN ANS 6
Effective for models beginning May 2007, having a serial
number ending with the letter ‘A’... e.g. xxxxxx07122A
