KID KART PARTS MANUAL PAGE 1.50 MAY 2007 A.R.T. GROUP
WHEEL / CASTER ASSEMBLIES - VENTILATOR BASE
XPRS0X38
ITEM NUMBER DESCRIPTION QTY
8 9770104001 BALL LOCK PIN - AXLE - 57193-1 2
9 9650701021 NYLOCK NUT, LOW 1/2-20 ZPS 2
8-9 900080 KID KART AXLE ASSEMBLY
10 9630204526 HEX BOLT 5/16-18 x 3-1/4 GRADE 5 ZPS 2
11 9640160761 WASHER 3/8” x 1/2” FLAT SS 4
1-5,10-11 900081 KID KART CHROME FORK ASSEMBLY
1-6A,10-11 9180600004 CASTER ASSY - 8” PNEUMATIC
1-6B,10-11 9180600006 CASTER ASSY - 8” w/AIRLESS INSERT
ITEM NUMBER DESCRIPTION QTY
1 9651001021 ACORN NUT 1/2-20 BRASS CHROME 2
2 9640181205 WASHER 1/2” FLAT NYLON 2
3 9740818071 BEARING 1/2” - FLANGED 2
4 9720813001 CASTER FORK w/STEM 8” CHROME 2
5 9650501014 NYLOCK NUT 5/16-18 ZPS 2
6A 9710802003 CASTER 8” - PNEUMATIC 2
6B 9710802004 CASTER 8” - w/AIRLESS INSERT 2
7A 9711402003 WHEEL 14” - PNEUMATIC 2
7B 9711402401 WHEEL 14” - w/AIRLESS INSERT 2
