12.47.3 Diagnostic page–Send Diagnostic
The Diagnostic page instructs the drive to turn the drive fault LED on or off. This page is used only by the Send
Diagnostic command (see Table 210).
Field definitions (listed alphabetically)
Page Code
A0h
Diagnostic page-Send Diagnostic command page code.
Page Length
000Ah
The length (in bytes) of the Diagnostic—Send Diagnostic page.
SBDL (Set Bad Device Light)
1
Turn on the drive fault LED.
0 Turn off the drive fault LED.
Table 210: Diagnostic page–Send Diagnostic command
Bit
Byte
7 6 5 4 3 2 1 0
0
Page Code (A0h)
1
Reserved
2 (MSB)
Page Length (0002h)
3 (LSB)
4
Reserved
5 Reserved SBDL
Table
number
210
210
210
