140 Fibre Channel Interface Manual, Rev. D
11.5 FCP RSP
An FCP Response (RSP) frame is returned by the drive for each FCP CMND operation unless the drive
receives:
1. A Clear Task Set
2. An Abort Task Set
3. A Target Reset
4. A Loop Initialization Primitive Sequence (LIP) Reset
5. An Abort Sequence (ABTS) for the command
Table 84: FCP RSP header
Bit
Byte 7 6 5 4 3 2 1 0
0 0 0 0 0 0 1 1 1
R_CTL
1 (MSB)
2 D_ID
3 (LSB)
4 0 0 0 0 0 0 0 0
Reserved
5 (MSB)
6 S_ID
7 (LSB)
8 0 0 0 0 1 0 0 0
Type
9 (MSB)
10 F_CTL
11 (LSB)
12
SEQ_ID
13 0 0 0 0 0 0 0 0
DF_CTL
14 0 0 0 0 0 0 0 0
15 0 0 0 0 0 0 0 0
SEQ_CNT
16 (MSB) OX_ID
17 (LSB)
18 1 1 1 1 1 1 1 1
19 1 1 1 1 1 1 1 1
RX_ID
20 (MSB)
Parameter
21
22
23 (LSB)
