10.5.3.2
Device Address page
Field definitions (listed alphabetically)
Action Code
01h
Device Address
ESI Page
00h
Identifies the ESI page code used (00h).
Node Name
The 64-bit Fibre Channel unique Name_Identifier assigned to the drive.
Page Length
24h
The length of the ESI page (in bytes).
Table 65:
Device Address page
Bit
Byte
7
6
5
4
3
2
1
0
0
0
0
0
0
ESI Page (00h)
1
0
0
0
0
Action Code (01h)
2
3
(MSB)
Page Length (24h)
(LSB)
4
(MSB)
Node Name
:
11
(LSB)
12
Port A (01h)
13
(MSB)
Port A Port_Identifier
14
15
(LSB)
16
Port A Position
17
0
0
0
0
0
0
0
0
18
(MSB)
Port A Name
:
25
(LSB)
26
Port B (02h)
27
(MSB)
Port B Port_Identifier
28
29
(LSB)
30
Port B Position
31
0
0
0
0
0
0
0
0
32
(MSB)
Port B Name
:
39
(LSB)
