11.3 FCP XFER RDY
The FCP XFER RDY (Transfer Ready) frame is sent by the drive when it requests data for a transfer to the
drive. Examples of commands resulting in data transfers to the drive are Write, Mode Select, and Write Buffer.
Table 80: FCP XFER RDY header
Bit
Byte 7 6 5 4 3 2 1 0
0 0 0 0 0 0 1 0 1
R_CTL
1 (MSB)
2 D_ID
3 (LSB)
4 0 0 0 0 0 0 0 0
Reserved
5 (MSB)
6 S_ID
7 (LSB)
8 0 0 0 0 1 0 0 0
Type
9 (MSB)
10 F_CTL
11 (LSB)
12
SEQ_ID
13 0 0 0 0 0 0 0 0
DF_CTL
14 0 0 0 0 0 0 0 0
15 0 0 0 0 0 0 0 0
SEQ_CNT
16 (MSB)
OX_ID
17 (LSB)
18 1 1 1 1 1 1 1 1
19 1 1 1 1 1 1 1 1
RX_ID
20 (MSB)
Parameter
21
22
23 (LSB)
