Fibre Channel Interface Manual, Rev. D
199
Field definitions (listed alphabetically)
Parameter Code
80FFh
Command Initiate Port Code. This field identifies the port on the drive that receives the Log Sense command
and requested transfer of this page.
0 = Port A.
1 = Port B.
Field definitions (listed alphabetically)
Parameter Code
Code
Length
Description
8100h
4 bytes
Link Failure Count, Port A. Count of the number of Loss of Sync conditions that have occurred on
Port A which exceeded 100 msecs in duration.
8101h
4 bytes
Loss of Synchronization Count, Port A. Count of the number of short (< 100 msecs) Loss of Syn-
chronization conditions that have occurred on Port A.
8104h
4 bytes
Invalid Transmission Word Count, Port A. Count of the number of invalid transmission words/Run-
ning Disparity errors that have been detected on Port A.
8105h
4 bytes
Invalid CRC Count, Port A. Count of the number of write data frames that have been received
with invalid CRCs on port A. These errors are only detected when this drive is the target of the
data transfer.
8106h
4 bytes
LIP F7 Initiated Count, Port A. Count of the number of LIP F7s (Initialize LIP) which the drive has
initiated on Port A.
8107h
4 bytes
LIP F7 Received Count, Port A. Count of the number of LIP F7s (Initialize LIP) which the drive has
received on Port A.
8108h
4 bytes
LIP F8 Initiated Count, Port A. Count of the number of LIP F8s (Failure LIP) which the drive has
initiated on Port A.
Table 132: Command Initiate Parameter Format
Bit
Byte
7
6
5
4
3
2
1
0
0
1
Parameter Code (80FFh)
2
0
1
1
0
00
1
1
3
02h
4
Reserved
5
Reserved
CIP
Table 133: Fibre Channel Link Format
Bit
Byte
7
6
5
4
3
2
1
0
0
1
Parameter Code
2
0
1
1
0
00
1
1
3
04h
4
5
6
7
Counter Data
Table
number
Table
number
