Field definitions (listed alphabetically)
Action Code
07h
Link Status.
ESI Page
00h
Identifies the ESI page code used (00h).
Invalid CRC Count
The count of the number of write data frames that have been received with invalid CRCs on the port. These errors are only
detected when this drive is the target of the data transfer.
Invalid Transmission Word Count
The count of the number of invalid transmission words/running disparity errors that have been detected on the port.
52
.
55
(MSB)
Link Failure Count, Port B
(LSB)
56
.
59
(MSB)
Loss of Sync Count, Port B
(LSB)
60
.
63
(MSB)
Loss of Signal Count, Port B
(LSB)
64
.
67
(MSB)
Primitive Sequence Protocol Error, Port B
(LSB)
68
.
71
(MSB)
Invalid Transmission Word Count, Port B
(LSB)
72
.
75
(MSB)
Invalid CRC Count, Port B
(LSB)
76
.
79
(MSB)
LIP F7 Initiated Count, Port B
(LSB)
80
.
83
(MSB)
LIP F7 Received Count, Port B
(LSB)
84
.
87
(MSB)
LIP F8 Initiated Count, Port B
(LSB)
88
.
91
(MSB)
LIP F8 Received Count, Port B
(LSB)
92
.
99
Reserved
Table 70:
Link Status page (Continued)
Bit
Byte
7
6
5
4
3
2
1
0
Table
number
