288 Fibre Channel Interface Manual, Rev. D
Page Code
The Page Code number of the Diagnostic page to be received. See Table 190 for page code numbers and descriptions.
PCV (Page Code Valid)
0
The Page Code is ignored. The data received is the page of data prepared by the drive as the result of the most
recently completed Send Diagnostic command. This data could also be the Self Test Diagnostic results which has
no Page Code number, but is described in Table 197.
1 The Page Code in the Page Code field is valid. The contents of the Page Code field defines the data returned by
this command.
Field definitions (listed alphabetically)
Page Code
00h
Provides the supported diagnostic pages information for the drive.
Page Length
n - 3
The length (in bytes) of the Supported Diagnostic page.
Supported Page List
A list of all diagnostic page codes implemented by the disc drive in ascending order beginning with page code 00h. The
disc drive presently supports the pages listed in Table 192.
Table 190: Receive Diagnostics page code descriptions
Page Code Description Reference Table
00h List of Supported Diagnostic Pages 191
01h - 0Fh SCSI Enclosure Services Pages 193
40h Address Translation Page 194
none Default Self Test Diagnostic Results 197
Table 191: Supported Diagnostic Pages format
Bit
Byte
7 6 5 4 3 2 1 0
0
Page Code (00h)
1
Reserved
2
(MSB)
Page Length (n–3)
3 (LSB)
4
:
n
Supported Page List
Table 192: Supported Send Diagnostic pages
Page Code Description Reference
00h Supported Diagnostic pages Table 191
01h - 0Fh SCSI Enclosure Services Information (ESI) pages Table 193
40h Translate Address page Table 194
189
189
Table
number
191
191
191
