Woodstock M1013 User Manual
Page 6
-4-
M1013 Owner's Manual (Mfg. Since 6/09)
IN
TR
O
DU
CT
IO
N
Overall Dimensions
Weight .................................................................................................................. 150 lbs.
Length ......................................................................................................................... 39"
Width .......................................................................................................................23
3
⁄
8
"
Height ......................................................................................................................54
3
⁄
4
"
Foot Print (Length/Width) .....................................................................................26
1
⁄
2
" x 20
1
⁄
2
"
Construction Materials
Table .............................................................................................. Precision-Ground Cast Iron
Wheels ..................................................................................................... Machined Cast Iron
Body ..................................................................................................................... Cast Iron
Base ..............................................................................Formed & Welded Steel w/Coolant Sump
Wheel Cover ..................................................................................................... Formed Steel
Paint ........................................................................................................................Epoxy
Shipping Dimensions
Weight ................................................................................................................... 176 lbs.
Length ......................................................................................................................... 41"
Width .......................................................................................................................... 19"
Height ......................................................................................................................... 22"
Electrical
Switch ..................................................................................................... Automatic Shut-Off
Switch Voltage .............................................................................................................110V
Cord Length ................................................................................................................. 6 ft.
Cord Gauge ............................................................................................................18 gauge
Recommended Breaker Size for 110V ................................................................................... 15A
Recommended Breaker Size for 220V ................................................................................... 15A
Included Plug Type ................................................................................................. NEMA 5-15
Other
Wheel Size .................................................................................................................... 13"
Blade Guides .............................................................................................. Adjustable Carbide
ISO Factory ............................................................................................................ ISO 9001
Country of Origin ......................................................................................................... China
Warranty ................................................................................................................. 2 Years
Serial Number Location .................................................................Machine ID Label on Body Frame
Assembly Time ......................................................................................................30 Minutes
Features
Control Panel Conveniently Located
Adjustable Hydraulic Downfeed
Quick Release Vise for Rapid Workpiece Change-Out
Blade Included
Model M1013 Machine Specifications, Page 2 of 2
