5. Adjust the cast iron stop for duplicate cuts and
install the ejector chute if required.
6. Loosen the headstock lock lever (Figure 24), and
swivel the headstock to the needed angle of cut, and
lock the lever in place.
7. Set the blade guide so the guides hold the blade
close to the workpiece, and the blade will not
twist with a cutting load (refer to
Blade Guides on
Page 19 for detailed instructions).
8. Open the feed ON/OFF valve and turn the feed
rate knob so the feed rate is correct, based on your
observations of the blade chip characteristics. Refer
to
Feed Rate on Page 25 for detailed instructions.
Note: When the cut is complete, the ON/OFF switch
push lever will shut OFF the bandsaw.
Figure 24. Headstock swivel system.
Lock Lever
