-39-
M1013 Owner's Manual (Mfg. Since 6/09)
PA
RT
S
Stand Assembly Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
200 XM1013200 BASE 220 XM1013220 PLATE
202 XPB26M HEX BOLT M8-1.25 X 30 221 XPCAP30 CAP SCREW 5/16-18 X 1/2
203 XPLW04M LOCK WASHER 8MM 222 XPS04 PHLP HD SCR 1/4-20 X 1/2
204 XM1013204 SCALE 223A XM1013223A BRACKET W/NUT V2.01.08
208 XM1013208 EJECTOR PLATE 225 XPSS03 SET SCREW 1/4-20 X 3/8
209 XPSS17 SET SCREW 5/16-18 X 5/16 226 XM1013226 BUSHING
210 XM1013210 DISTANCE SET BRACKET 227 XPLW01 LOCK WASHER 5/16
211 XM1013211 STOCK STOP ROD 1/2" 228A XM1013228A ACME SCREW V2.01.08
212 XPW01M FLAT WASHER 8MM 229A XM1013229A VISE BASE V2.01.08
213 XPB03M HEX BOLT M8-1.25 X 16 230 XPW07 FLAT WASHER 5/16
214 XM1013214 DELUXE STAND ASSEMBLY 231 XPCAP69 CAP SCREW 5/16-18 X 1/4
214-6 XM1013214-6 SHOP FOX LOGO 2-5/16" X 5" 232A XM1013232A VICE HALF V2.01.08
215 XM1013215 RUBBER FOOT 233A XM1013233A WALL PLATE V2.01.08
216 XM1013216 WHEEL ROD 234 XPW07 FLAT WASHER 5/16
217 XM1013217 COTTER PIN 1/8 X 1 235 XPB07 HEX BOLT 5/16-18 x 3/4
218 XM1013218 WHEEL 236 XPCAP08 CAP SCREW 5/16-18 X 1-1/2
218-1 XPW27MM FLAT WASHER 17MM 338 XM1013338 STRIPE FOR STAND 6" X 4'
219 XM1013219 HANDWHEEL ASSEMBLY
