MACHINE
SPECIFICATIONS
Motor
Type ..........................................................................................TEFC Capacitor Start Induction
Horsepower ...............................................................................................................
1
⁄
2
HP
Voltage ................................................................................................................ 110/220V
Prewired ..................................................................................................................... 110V
Phase ....................................................................................................................... Single
Amps ................................................................................................................... 8/4 Amps
Speed .................................................................................................................. 1725 RPM
Cycle ........................................................................................................................ 60 Hz
Number Of Speeds ............................................................................................................. 1
Power Transfer .................................................................................................... V-Belt Drive
Bearings ............................................................................................... Sealed and Lubricated
Main Specifications
Operation Info
Blade Speeds ..........................................................................................80, 120, 200 FPM
Blade Length ........................................................................................................64
1
⁄
2
"
Head Swivel ........................................................................................................... 45°
Cutting Capacities
Angle Cuts .......................................................................................... 45° Right, 60° Left
Vise Jaw Depth ...................................................................................................... 4
3
⁄
8
"
Vise Jaw Height ..................................................................................................... 2
1
⁄
2
"
Max. Capacity Rectangular Height @ 90° .......................................................................... 5"
Max. Capacity Rectangular Width @ 90° ........................................................................... 6"
Max. Capacity Rectangular Height @ 60° ....................................................................... 1
3
⁄
4
"
Max. Capacity Rectangular Width @ 60° ....................................................................... 2
3
⁄
16
"
Max. Capacity Rectangular Height @ 45° ......................................................................2
15
⁄
16
"
Max. Capacity Rectangular Width @ 45° ........................................................................ 3
3
⁄
4
"
Max. Capacity Round @ 90° .......................................................................................... 5"
Max. Capacity Round @ 60 ......................................................................................... 1
3
⁄
4
"
Max. Capacity Round @ 45° ....................................................................................... 3
3
⁄
4
"
Table info
Length ................................................................................................................... 12"
Width .................................................................................................................. 4
1
⁄
2
"
Floor To Cutting Area Height ........................................................................................ 29"
MOdEl M1013
5" X 6" METAl CUTTING BANdSAW
Model M1013 Machine Specifications, Page 1 of 2
Machine Specifications
