-16-
M1013 Owner's Manual (Mfg. Since 6/09)
SE
TU
P
Automatic OFF
Adjustment
After you have removed the shipping strap and have
adjusted the headstock stop bolt, you must adjust the
OFF button lever stop bolt, so the bandsaw shuts OFF
automatically when a cut is complete.
To set the adjust the OFF button, do these steps:
1. With the headstock in the complete down position,
loosen the 12mm stop bolt and jam nut shown in
Figure 15.
2. Push down on the OFF button lever so the button is
completely depressed.
3. While keeping the lever depressed, use your
fingertips to turn the stop bolt until the head just
touches the lever.
4. Back off the stop bolt 1 ⁄
3
turn and tighten the jam
nut.
Figure 15. Automatic OFF components.
Stop Bolt
& Jam Nut
OFF Button
Lever
