-37-
M1013 Owner's Manual (Mfg. Since 6/09)
PA
RT
S
Saw Assembly Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
100 XM1013100 BODY FRAME 132 XPN02 HEX NUT 5/16-18
102 XPB41 HEX BOLT 1/2-12 X 1-1/2 134 XM1013134 MOTOR MOUNT PLATE
104 XM1013104 GEAR BOX GASKET 135 XM1013135 KNOB BOLT 5/16-18 X 1-3/4
105 XM1013105 PLATE 136 XPB07 HEX BOLT 5/16-18 x 3/4
107 XPVA23 V-BELT A-23 137 XPW07 FLAT WASHER 5/16
109 XM1013109 PULLEY 138 XPN08 HEX NUT 3/8-16
110 XM1013110 BEARING COVER 139 XM1013139 SWITCH CUT OFF TIP
111 XM1013111 OIL SEAL 140 XPCAP04 CAP SCREW 1/4-20 X 1/2
112 XPS24 PHLP HD SCR 8-32 X 3/8 141 XPB24 HEX BOLT 3/8-16 X 1-1/4
113 XPB03 HEX BOLT 5/16-18 X 1 144 XM1013144 RIGHT SAFETY GUARD (OPTION)
114 XPB07 HEX BOLT 5/16-18 x 3/4 145A XM1013145A STOP BOLT 3/8-16 X 1 V2.10.06
115 XPB02 HEX BOLT 1/4-20 X 5/8 147 XPK23M KEY 5 X 5 X 25
116 XM1013116 BLADE TENSION SLIDING GUIDE 148 XM1013148 FRONT BLADE WHEEL
117 XPW07 FLAT WASHER 5/16 150 XPR05M EXT RETAINING RING 15MM
118 XM1013118 SHAFT BLOCK 151 XPSS17 SET SCREW 5/16-18 X 5/16
119 XM1013119 COMPRESSION SPRING 152 XPW07 FLAT WASHER 5/16
120 XM1013120 BLADE TENSION KNOB 153 XPB07 HEX BOLT 5/16-18 x 3/4
121 XPW02 FLAT WASHER 3/8 154 XM1013154 BLADE 1/2" X 0.025" X 64-1/2"
123 XM1013123 BLADE TENSION SLIDING PLATE 156 XM1013156 KNOB BOLT 3/8-16 X 1-1/4
124 XPSS38 SET SCREW 5/16-18 X 5/8 159 XM1013159 LEFT SAFETY GUARD
126 XPS08M PHLP HD SCR M5-.8 X 12 160 XM1013160 KNOB BOLT 1/4"-20 X 5/8"
127 XM1013127 BUSHING 161 XPW06 FLAT WASHER 1/4
128 XPCAP05 CAP SCREW 1/4-20 X 3/4 162A XM1013162A PLASTIC SAFETY COVER V2.08.06
129 XPN05 HEX NUT 1/4-20 163 XPS06 PHLP HD SCR 10-24 X 3/8
130 XM1013130 WIRE CLAMP 164 XPSS17M SET SCREW M8-1.25 X 6
131 XPS06 PHLP HD SCR 10-24 X 3/8
