PassThru
PassThru Mode is used to communicate directly to the Raven
internal hardware.
Caution: While the modem is in PassThru mode, ALEOS is disabled.
If you need to connect to the Raven while it is in PassThru mode, you
will need to do so with a terminal application. Not all commands are
available while the modem is in PassThru mode.
Figure 1-7: AceManager : PassThru
\APASSTHRU
Note: This mode is not available
through the remote AT telnet
server. You will need to connect
to the Raven with it connected
directly to your computer. Sets the modem operation to pass through mode. This mode
will pass any characters received on the port Ethernet directly
to the internal hardware module and output any characters
from the internal hardware module out the port Ethernet. This
allows direct access/configuration of the hardware module.
Once this mode is entered, the unit must be physically reset to
return to normal operation. This command is not available in
AceManager.
Note: It may take up to 30 seconds for the hardware module to
respond after CONNECT is output.
*CSX1=n
PassThru Echo : Echo data to the host.
• n=0 : Data will be passed to the host.
• n=1 : PASSTHRU mode will echo all host received data
and will not pass the data to the modem while the modem
is not asserting DCD.
Note: If the modem is asserting DCD, data will be passed from the
host to the modem as it normally is when *CSX1=0.
