Circuit Switch Communications
Rev 3.0B Feb.08 114
Figure 2-12: Raven: Reset
e. Wait until the modem REG indicator is lit and then
proceed to the next step.
8. Configure the Raven using a
AceManager template.
Caution: Do not proceed to this step before the REG indicator light is
lit.
a. Click the Refresh All button on the tool bar of
AceManager and wait until all of the modem infor‐
mation is loaded into the AceManager application.
Figure 2-13: AceManager : Refresh All
b. Click the Load button on the tool bar.
Figure 2-14: AceManager : Load
c. Change to the folder (directory) where you
downloaded the template(s) and select the template
for your modem model and/or preferred mode.
Figure 2-15: AceManager : Template
