Sierra Raven EDGE - Manual (Page 25)

Activating Raven on your cellular provider Network
Rev 3.0B Feb.08 21
Figure 3-5: Inserting the SIM
6. Finishing the SIM installation
a. Slide the Raven back into the case.
b. Secure the back of the Raven with the screws.
Configuring the APN
The APN (Access Point Name) is the way your modem knows
how it will be communicating with the network. The APN
allows custom IP addressing and tailoring your companyʹs
wireless IP solution to meet the security and IP addressing
requirements of your applications.
Note: Most accounts use the default addressing solution of Private or
Public IP addresses supplied by the Internet and Proxy APNs. Only if
you have a Static or Custom IP address should you need to configure
a custom APNs.
The default APN is Internet. If you need a different APN, use
can use AceManager to configure it.
1. Start AceManager
Start > All Programs > AirLink Communications > AceManager 3G
> AceManager 3G
