Activating Raven on your cellular provider Network
Rev 3.0B Feb.08
19
•
Slim stylus ‐ A PDA stylus, an unbent paperclip, or other
such item.
1. Opening the Case
a.
Unplug the Raven power and all cables.
b.
Using a small phillips head screw driver, remove the
screws on the back of the Raven.
c.
Slide the case off of the Raven and set it aside.
Figure 3-1: Partially removed case
2.
a.
Carefully remove the SIM card from the card you got
from your cellular provider.
3. Ejecting the SIM tray
Tip: The button is between two boards.
Figure 3-2: SIM tray button
