Print length, expanded – SATO XL400/410 User Manual
Page 75
Programming Manual
2. Command Codes
SATO RISC Printers
75
Print Length, Expanded
Command Structure:
Normal length
Expanded length
AX:
Sets the print length to 14" (356 mm)
AR:
Resets the maximum print length to 7" (178 mm)
Example:
See above
Placement:
Must follow the Start Code command and be in it’s own
separate data stream.
Default:
Function:
To double the maximum print length (in feed direction) for a label.
Input:
Note:
1. AX is effective until AR is sent to reset the printer to its standard
print length, or until the printer is repowered.
2. It may be included in an independent data stream to specify the
size of the maximum print area.
