Programming Manual 2. Command Codes
SATO RISC Printers 109
Memory Card Function
Graphics, Custom Store
Command Structure:
GIabbbcccddd{data}
a:
Specifies character format of the data
H
Hex data
B Binary data
bbb: Number of horizontal 8 x 8 blocks (001-248)
ccc: Number of vertical 8 x 8 blocks (001-267)
ddd: Graphics storage number (001-999)
{data}: Hex or binary data to describe the graphic image
Placement: Immediately following the CC Slot Select com-
mand.
Default: None
Function:
To provide similar functionality to the G Custom Graphic com-
mand, but allows for the graphic image to be stored in a Memory Card.
Use the Store command to send the graphic data to the printer, which
is held in the optional memory card, even if printer power is lost.
Input:
A
CC1GIH002002001
0100038007C00FE01FF03FF87FFCFFFE07C007C007C007C007C00
7C007C007C0
Z
Output:
There is no printer output as a result of this command. See GR
Recall Custom Graphics command.
Note:
1. You must have the optional Memory Card to use this command.
Call your SATO representative for details.
2. The maximum storage capacity is 999 graphics, up to the capac-
ity of the memory card used.
3. If a data transmission error occurs, the printer will beep and the
“ERROR” LED will come on. You must then retransmit the image.
4. Each graphic to be stored must be sent in its own data stream.
Example of correct data stream:
A
