Characters, custom-designed – SATO XL400/410 User Manual
Page 32
32
SATO RISC Printers
2. Command Codes
Programming Manual
Characters, Custom-Designed
Command Structure:
Store Command
Recall command
a:
Matrix size
1: 16x16 matrix
2: 24x24 matrix
b:
Specifies the character encoding method for the data
stream
H: Hexadecimal characters
B: Binary characters
cc:
Memory location to store/recall the character. Valid
memory locations are 21 to 52 (counting in Hex) or “!”
to “R” in Binary
{data}
Data to describe the character
Example:
Placement:
The Store command is typically sent in its own data st-
ream to the printer, between the Start/Stop commands.
The Recall command is sent in a secondary data st-
ream to print the character,and follows any necessary
position or size commands.
Default:
None
Function:
To allow for the creation, storage, and printing of custom characters,
such as special fonts or logos. Up to 50 individual characters may be
stored in the custom character volatile memory.
