Programming Manual 4. Bar Code Specifications
SATO RISC Printers 153
Note:
1. If any of the parameters entered are outside the valid range, a
symbol will not be printed when the DC Print Data com-
mand is sent to the printer.
2. The number of cells per line (eee) and the number of cell lines (fff)
should be specified as all zeroes, allowing the printer to automat-
ically calculate the optimum configuration for the symbol.
3. The Reference Point for the Data Matrix symbol is the upper-left
corner. If an R Rotate command is used to rotate the sym-
bol, it will rotate in the counter-clockwise direction.
4. The Format ID specified for “aa” is defined by the following table.
The printer only supports the Format ID’s defined in the table.
5. The maximum number of data characters that can be specified for
either the 16-Bit or 32-Bit CRC modes is 500.
ID
Number CHARACTER SET
ENCODING
SCHEME
16 Bit CRC
01 Numeric, Space Base 11
02 Upper Case Alpha, Space Base 27
03 Upper Case Alpha, Space,Comma,
Period, Slash, Minus
Base 41
04 Upper Case Alphanumeric, Space Base 37
05 ASCII 7-bit, Full Keyboard (20H -7FH) ASCII
06 ISO 8-bit, International (20H -FFH) 8-Bit
32 Bit CRC
11 Numeric, Space Base 11
12 Upper Case Alpha, Space Base 27
13 Upper Case Alpha, Space, Comma,
Period, Slash, Minus
Base 41
14 Upper Case Alphanumeric, Space Base 37
15 ASCII 7-bit, Full Keyboard (20H -7FH) ASCII
16 ISO 8-bit, International (20H -FFH) 8-Bit
