75 Software
Graphics Environment Setup (Maps) (Continued)
(Allocation Setup Screen)
(1) Matrix/Mux-Dvr
Allocates functions and selects video
equipment and cameras for operation.
(2) Movements
Allocates dome camera automatic
functions.
See Protocol Chart (Autopan/Patrol).
(P79, 80)
(3) Focus/Iris
Allocates camera focus and iris functions.
(4) Jump page
Allocates Map switching functions
(Password levels can be set to perform this
function).
(5) Aux
Allocates other camera functions.
(6) Wiper/Washer
Allocates wiper and washer functions.
(7) Save and exit
Click when allocation is complete.
This saves the settings and exits the
allocation setup screen.
To exit the allocation screen without
saving, click “Exit”.
(1)
(2)
(3) (4)
(7)
(6)
(5)
