VR-609
5.3.2.2 Events
・Checks event you want to detect from the Events menu by using Jog and ENTER
button.
・Each event type is indicated by the following.
・Disk Full : When HDD is fully recorded.
・Admin.PW Changed : When Admin Password has been changed.
・Video Loss : No video image. Possible to select channel number or ALL.
・Motion : When motion is detected. Possible to select channel number or ALL.
・How to off “Alarm” when alarm has occurred
・Auto : Alarm is turned off automatically after setting time.
・Manual : As press the Alarm button on the front, alarm is turned off.
・Time (Sec) : This is for selecting “Auto”. (1-300 Sec)
5.3.2.3 Alarm Off
5.3.2.4 Alarm Output Number
・Select Alarm Output Number by using channel button.(1~4 buttons)
Alarm Output Number is changed according to pressing button.
・For Alarm OUT connector, please refer to P.29
