VR-609
○ : Always Recording.
A : Alarm Recording.
M : Motion Recording.
F(fps)/F(fps) : The first ‘fps’ means field rate of Always Recording, The second
‘fps’ means field rate of Alarm Recording/ Motion Recording.
・The left numbers indicate the input channel. (1 - 9)
・"QL" indicates quality level as recording.
・"AR" indicates whether Audio Recording or not.
2) Channel
3) Quality Level, Audio Recording
4) Recording Events
The left picture indicates it is being Always Recording with
recording 3fps.
The left picture indicates it is being Alarm, Motion Recording
with recording 4fps.
Ex)
5.2.2.1 Explanation of Recording Schedule
・The above numbers indicate the hour in the day. (00 - 23)
1) Time
