Intel Desktop Board D865PCD Technical Product Specification
86
4.4.4.1 PATA Submenus
To access these submenus, select Advanced on the menu bar, then Drive Configuration, and then
the master or slave to be configured.
Maintenance Main Advanced Security Power Boot Exit
PCI Configuration
Boot Configuration
Peripheral Configuration
Drive Configuration
SATA Port-0
SATA Port-1
PATA Primary Master
PATA Primary Slave
PATA Secondary Master
PATA Secondary Slave
Floppy Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
There are four available submenus in this screen:
• PATA primary master
• PATA primary slave
• PATA secondary master
• PATA secondary slave
Table 48 on page 87 shows the format of the PATA IDE submenus. For brevity, only one example
is shown.
✏
NOTE
SATA support is not present on the Desktop Board D865PCD. The SATA submenus in this BIOS
screen are not accessible.
