Intel Desktop Board D865PCD Technical Product Specification
84
Table 46. Peripheral Configuration Submenu (continued)
Feature Options Description
Parallel port • Disabled
• Enabled
• Auto (default) Configures the parallel port.
Auto assigns LPT1 the address 378h and the interrupt IRQ7.
An * (asterisk) displayed next to an address indicates a
conflict with another device.
Mode • Output Only
• Bi-directional
(default)
• EPP
• ECP
Selects the mode for the parallel port. Not available if the
parallel port is disabled.
Output Only operates in AT*-compatible mode.
Bi-directional operates in PS/2-compatible mode.
EPP is Extended Parallel Port mode, a high-speed
bi-directional mode.
ECP is Enhanced Capabilities Port mode, a high-speed
bi-directional mode.
Base I/O address
(This feature is present
only when Parallel Port
is set to Enabled) • 378 (default)
• 278 Specifies the base I/O address for the parallel port.
Interrupt
(This feature is present
only when Parallel Port
is set to Enabled) • IRQ 5
• IRQ 7
(default)
Specifies the interrupt for the parallel port.
DMA
(This feature is present
only when Parallel Port
Mode is set to ECP) • 1
• 3 (default) Specifies the DMA channel.
Audio
• Enabled
(default)
• Disabled
Enables or disables the onboard audio subsystem.
Onboard LAN • Enabled
(default)
• Disabled
Enables or disables the onboard LAN device.
ASF Support
• Disabled
• Enabled
(default)
Enables or disables ASF (Alert Standard Format) support.
