Page 46
Intel Desktop Board D865PCD Technical Product Specification
46
2.8.2.2 Audio
Connectors
Figure 9 shows the location of the audio connectors.
OM17035
9
10
1
2
B
1
4
A
Item
Description
For more information see:
A
ATAPI CD-ROM (black)
B
Front panel audio
Figure 9. Audio Connectors
