Technical Reference
47
Table 16. ATAPI CD-ROM Connector
Pin Signal Name
1 Left audio input from CD-ROM
2 CD audio differential ground
3 CD audio differential ground
4 Right audio input from CD-ROM
Table 17. Front Panel Audio Connector
Pin Signal Name Pin Signal Name
1 Mono Mic in (Stereo Mic 1) 2 Ground
3 Mono Mic Bias (Stereo Mic 2) 4 +5 V
5 RIGHT_OUT 6 Right channel return
7 Ground 8 Key
9 LEFT_OUT 10 Left channel return
#
INTEGRATOR’S NOTE
The front panel audio connector is alternately used as a jumper block for routing audio signals.
Refer to Section 2.9.1 on page 56 for more information.
