BIOS Setup Program
85
4.4.4 Drive Configuration Submenu
To access this submenu, select Advanced on the menu bar and then Drive Configuration.
Maintenance Main Advanced Security Power Boot Exit
PCI Configuration
Boot Configuration
Peripheral Configuration
Drive Configuration
Floppy Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
The menu represented in Table 47 is used to configure IDE device options.
Table 47. Drive Configuration Submenu
Feature Options Description
PCI IDE Bus Master • Disabled
• Enabled (default) Enables/disables the use of DMA for hard drive BIOS
INT13 reads and writes.
Hard Disk Pre-Delay • Disabled (default)
• 1 Second
• 2 Seconds
• 3 Seconds
• 4 Seconds
• 5 Seconds
• 6 Seconds
• 9 Seconds
• 12 Seconds
• 15 Seconds
• 21 Seconds
• 30 Seconds Specifies the hard disk drive pre-delay.
SATA Port-0 None Not supported
SATA Port-1 None Not supported
PATA Primary Master Select to display
sub-menu Reports type of connected device on Parallel ATA
(PATA) IDE primary master interface.
PATA Primary Slave Select to display
sub-menu Reports type of connected device on Parallel ATA
(PATA) IDE primary slave interface.
PATA Secondary Master Select to display
sub-menu
Reports type of connected device on Parallel ATA
(PATA) IDE secondary master interface.
PATA Secondary Slave Select to display
sub-menu Reports type of connected device on Parallel ATA
(PATA) IDE secondary slave interface.
continued
