Intel Desktop Board D865PCD Technical Product Specification
32
Table 8. Power States and Targeted System Power
Global States
Sleeping States Processor
States
Device States Targeted System
Power
(Note 1)
G0 – working
state S0 – working C0 – working D0 – working
state. Full power > 30 W
G1 – sleeping
state S1 – Processor
stopped C1 – stop
grant D1, D2, D3 –
device
specification
specific. 5 W < power < 52.5 W
G1 – sleeping
state S3 – Suspend to
RAM. Context
saved to RAM. No power D3 – no power
except for
wake-up logic. Power < 5 W (Note 2)
G1 – sleeping
state S4 – Suspend to
disk. Context
saved to disk. No power D3 – no power
except for
wake-up logic. Power < 5 W (Note 2)
G2/S5 S5 – Soft off.
Context not saved.
Cold boot is
required.
No power D3 – no power
except for
wake-up logic. Power < 5 W (Note 2)
G3 –
mechanical off
AC power is
disconnected
from the
computer.
No power to the
system. No power D3 – no power for
wake-up logic,
except when
provided by
battery or external
source. No power to the system.
Service can be performed
safely.
Notes:
1. Total system power is dependent on the system configuration, including add-in boards and peripherals powered
by the system chassis’ power supply.
2. Dependent on the standby power consumption of wake-up devices used in the system.
1.11.1.2 Wake-up Devices and Events
Table 9 lists the devices or specific events that can wake the computer from specific states.
Table 9. Wake-up Devices and Events
These devices/events can wake up the computer… …from this state
LAN S1, S3, S4, S5 (Note)
Modem (back panel Serial Port A) S1, S3
PME# signal S1, S3, S4, S5 (Note)
Power switch S1, S3, S4, S5
PS/2 devices S1, S3
RTC alarm S1, S3, S4, S5
USB S1, S3
Note: For LAN and PME# signal, S5 is disabled by default in the BIOS Setup program. Setting this option to Power On
will enable a wake-up event from LAN in the S5 state.
