OCPRF100 MP Server System Technical Product Specification
Revision 1.0
51
4.2.11 SCSI Connector
Table 4-14: SCSI Connector
WIDE SCSI CONNECTOR
Pin Signal Signal Pin
1 S1 (+DB 12) S35 (-DB 12) 35
2 S2 (-DB 13) S36 (-DB 13) 36
3 S3 (+DB 14) S37 (-DB 14) 37
4 S4 (+DB 15) S38 (-DB 15) 38
5 S5 (+DB P1) S39 (-DB P1) 39
6 S6 (+DB 0) S40 (-DB 0) 40
7 S7 (+DB 1) S41 (-DB 1) 41
8 S8 (+DB 2) S42 (-DB 2) 42
9 S9 (DB 3) S43 (-DB 3) 43
10 S10 (+DB 4) S44 (-DB 4) 44
11 S11 (+DB5) S45 (-DB 5) 45
12 S12 (+DB 6) S46 (-DB 6) 46
13 S13 (+DB 7) S47 (-DB 7) 47
14 S14 (+DB P) S48 (-DB P) 48
15 S15 S49 49
16 S16 (DIFFSENS) S50 50
17 S17 (TERMPWR) S51 (TERMPWR) 51
18 S18 (TERMPWR) S52 (TERMPWR) 52
19 S19 (RESERVED) S53 (RESERVED) 53
20 S20 S54 54
21 S21 (+ATN) S55 (-ATN) 55
22 S22 S56 56
23 S23 (+BSY) S57 (-BSY) 57
24 S24 (+ACK) S58 (-ACK) 58
25 S25 (+RST) S59 (-RST) 59
26 S26 (+MSG) S60 (-MSG) 60
27 S27 (+SEL) S61 (-SEL) 61
