Chapter 2: Supported Reports

Netcool/Proviso Cisco IP Telephony Technology Pack User’s Guide, Version 4.3-W

93

PSTN Gateway E1/T1 Interface Utilization Resource

Description

Resource summary chart showing E1 or T1 interface utilization percentage.

Reporter Set

Interface

Tables and Charts

Tables: Resource Summary Table (1 of 1 implemented)

Charts: Resource Distribution Chart (2 of 2 implemented)

Metrics Used in Report

Interface Bandwidth Utilization In (percent)

Interface Bandwidth Utilization Out (percent)

Interface Throughput In (kbps)

Interface Throughput Out (kbps)

PSTN Gateway DS1 Active DS0 Channels (Nb)

Navigation Path

Navigation path on the DataView portal:

NOC Reporting > VOIP > Cisco > Infrastructure > PSTN Gateway > Interface > All

NOC Reporting > VOIP > Cisco > Infrastructure > PSTN Gateway > Interface > By Gateway

Drills Down To

PSTN Gateway E1/T1 Interface Utilization Resource Detail Chart

Drilled Down From

Top 10 E1/T1 Utilization Resource
