Invacare 9000 SL User Manual

Page 30

9000 Series

Part No. 1056953

SECTION 3

FRONT RIGGINGS

FRONT

RIGGINGS

HEEL LOOP REPLACEMENT (FIGURE 6)

1. Pull the cam lock lever UP to UNLOCKED position.
2. Perform one (1) of the following as shown in DETAIL "A" of FIGURE 6:

A. FOOTPLATES WITH SPRING BUTTONS: Push IN the release buttons and

remove the footplate assembly from the front rigging support.

B. BOLT-IN-PLACE FOOTPLATES:
Using a screw driver to hold the riv nut in position, remove the button head

screw from the riv nut.

Remove the riv nut and button head screw securing the footplate assembly to

the front rigging support.

3. Remove the mounting screw, spacer and locknut that secure the heel loop to the

footplate.

4. Remove EXISTING heel loop from slide tube.
5. Install NEW heel loop onto slide tube.
6. Install the mounting screw, spacer and locknut to secure the heel loop to the

footplate. Tighten until the spacer is secure.

7. Insert the lower footrest assembly into the upper footrest assembly to desired

height.

8. Perform one (1) of the following as shown in DETAIL "A" of FIGURE 6:

A. FOOTPLATES WITH SPRING BUTTONS: Ensure that the release buttons fully

protrude from holes on both sides of the upper footrest support.

B. BOLT-IN-PLACE FOOTPLATES:

From the outside of the swingaway front rigging, insert the riv nut through

both the front rigging support and the footplate assembly.

From the inside of the swingaway front rigging, insert the button head screw

through the appropriate adjustment hole and thread into the riv nut.

. Using a screwdriver to hold the riv nut in position, securely tighten the

button head screw. Torque to 32 in-lbs.

9. Rotate cam lock lever DOWN to LOCKED position.
