60
8
SET MODE
CI-V transceive
Transceive operation is possible with the IC-756 con-
nected to other Icom HF transceivers or receivers.
When “ON” is selected, changing the frequency, op-
erating mode, etc. on the IC-756 automatically
changes those of connected transceivers (or re-
ceivers) and vice versa.
O N O F F
Transceive ON
(default) Transceive OFF
CI-V with IC-731
When connecting the IC-756 to the IC-735 for trans-
ceive operation, you must change the operating fre-
quency data length to 4 bytes.
• This item must be set to “ON” only when operating trans-
ceiver with the IC-735.
O F F O N
5 bytes of frequency data
(default) 4 bytes of frequency data
■ Miscellaneous (others) set mode
(continued)
CI-V baud rate
This item sets the data transfer rate. 300, 1200, 4800,
9600, 19200 bps and “AUTO” are available.
When “AUTO” is selected, the baud rate is automati-
cally set according to the connected controller or re-
mote controller.
A U T O 1 9 2 0 0
Auto baud rate
(default) 19200 bps
CI-V address
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-756’s address is 50h.
When 2 or more IC-756’s are connected to an op-
tional CT-17
CI-V LEVEL CONVERTER , rotate the tuning
dial to select a different address for each IC-756 in
the range 01h to 7Fh.
5 0 h 7 F h
Address of 50h
(default) Address of 7Fh
