Page 27
AUTO TUNING STEP FUNCTION (AM/FM only)
When selecting AM or FM, the quick tuning step is au-
tomatically selected by the auto tuning step function.
24
3
FREQUENCY SETTING
■
Advanced tuning functions
QUICK TUNING STEP
The operating frequency can be changed in kHz
steps (1, 5, 9 or 10 kHz selectable) for quick tuning.
q
Push [TS] momentarily to display the quick tuning
indicator.
w
Rotate the tuning dial to change the frequency in
programmed kHz steps.
e
Push [TS] again to turn OFF the indicator.
r
Rotate the tuning dial for normal tuning if desired.
SELECTING THE kHz STEP
q
Push [TS] momentarily to turn the quick tuning
step ON.
w
Push [TS] for 2 sec. to enter the quick tuning step
setting display.
- Selected tuning steps for all modes appear.
e
Select the desired operating mode.
r
Push [F-1] – [F-4] to select the 1 kHz, 5 kHz, 9 kHz
or 10 kHz tuning step, respectively.
t
Repeat steps
e
and
r
to select quick tuning
steps for other modes, if desired.
y
Push [F-5] to exit the setting display.
1/4 TUNING STEP FUNCTION (RTTY only)
While operating in RTTY, the 1/4 function is available
for critical tuning. Dial rotation is reduced to 1/4 of nor-
mal when the 1/4 function is in use.
Push [1/4] to toggle the 1/4 function ON and OFF.
1/4
1/4
OFF
OFF
1/4
1/4
ON
ON
1/4 tuning step OFF
1/4 tuning step ON
SELECTING THE 1 Hz STEP
The minimum tuning step of 1 Hz can be used for fine
tuning.
q
Turn OFF the quick tuning step.
- “
▼
” does not appear.
w
Push [TS] for 2 sec. to toggle the 1 Hz tuning step
ON and OFF.
- RIT and/or
∂
TX also functions in 1 Hz tuning step
when used.
1ß
14.195.000
VFO
VFO
USB
USB
USB
USB
14.100.00
14.100.00
1ß 14.100.00
14.100.00
14.205.000
14.205.000
USB
USB
USB
USB
T X
FILTER
FILTER
SCAN
SCAN
MEMORY
MEMORY
SET
SET
VOX
VOX
OFF
OFF
COMP
COMP
OFF
OFF
SCOPE
SCOPE
ANT
ANT
1
METER
METER
Po
Po
P.AMP
P.AMP
OFF
OFF
ATT
ATT
OFF
OFF
AGC
AGC
MID
MID
2.4k
2.4k
9
2.8k
2.8k
455
455
12:34
12:34
VFO
VFO
1 Hz step indicator
14.100.00
VFO
VFO
USB
USB
USB
USB
14.205.00
14.205.00
T X
T X
1
ANT
ANT
1
METER
METER
Po
Po
2.4k
9
2.8k
455
12:34
Quick tuning indicator
R T T Y
5kHz
5kHz
10kHz
10kHz
9kHz
9kHz
BK-IN
BK-IN
OFF
OFF
1kHz
1kHz
AGC
AGC
MID
MID
[WHEN TS is ON]
[WHEN TS is ON]
EXIT
EXIT
S S B
1 k H z
1 k H z
1 k H z
1 k H z
C W
A M
F M
1 k H z
