DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 95
NAME PLATE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M1512400002 DECAL; GENERATOR CONTROL, DCAUSIXF ...... 1 ............ M11240000A
1 M1510300902 DECAL; GENERATOR CONTROL, DCAUSI2XF .... 1 ............ M11030090
2 M1512400122 DECAL; ENGINE OPERATING, DCAUSIXF .......... 1 ............ M11240012
2 M1510301002 DECAL; ENGINE OPERATING, DCAUSI2XF ......... 1 ............ M15000010
3 M1550000104 DECAL; NOTE ........................................................ 1 ............ M15000010
4 M1550000204 DECAL; NOTE ........................................................ 1 ............ M15000020
5 M1552000603 DECAL; AUXILLARY OUTPUT ............................... 1 ............ M15200060
6 M9500000004 DECAL; OIL DRAIN PLUG ..................................... 1 ............ M90000000
7 M9500100004 DECAL; WATER ...................................................... 1 ............ M90010000
8 M9500300004 DECAL; - ................................................................ 1 ............ M90030000
9 M9500300104 DECAL; + ............................................................... 1 ............ M90030010
10 M9500500004 DECAL; DIESEL FUEL, DCA25USIXF ................... 1 ............ M90050000
10 M9500500304 DECAL; DIESEL FUEL, DCA25USI2XF ................. 1 ............ M90050030
11 M9503000004 DECAL; WARNING MOVING PARTS ..................... 2 ............ M90300000
12 M9503000103 DECAL; WATER - OIL CHECK ............................... 1 ............ M90300010
13 M9503100004 DECAL; WARNING HOT COOLANT ....................... 1 ............ M90310000
14 M9503200004 DECAL; WARNING ENGINE EXHAUST ................. 1 ............ M90320000
15 M9510000004 DECAL; FLUID DRAIN ........................................... 1 ............ M91000000
16 M9510100004 DECAL; CAUTION HOT PARTS ............................. 1 ............ M91010000
17 M9512200004 DECAL; MQ ............................................................ 1 ............ M91220000
18 M9520000004 DECAL; GROUND .................................................. 1 ............ M92000000
19 M9520000104 DECAL; AMMETER CHANGE-OVER SW. ............. 1 ............ M92000010
20 M9520000204 DECAL; VOLTMETER CHANGE-OVER SW. .......... 1 ............ M92000020
21 M9520100004 DECAL; WARNING ELECTRIC SHOCK HAZARD . 2 ............ M92010000
22 M9520100204 DECAL; CAUTION .................................................. 1 ............ M92010020A
23 M9520100304 DECAL; SAFETY INSTRUCTION ........................... 1 ............ M92010030
24 M9520100404 DECAL; DANGER HIGH VOLTAGE ........................ 1 ............ M92010040
25 M9520100503 DECAL; WARNING ................................................. 1 ............ M92010050
26 M9520200003 DECAL; CONNECTION OF OUTPUT CABLE ........ 1 ............ M92020000
27 M9520200104 DECAL; OVER CURRENT RELAY ......................... 1 ............ M92020010
28 M1561000004 DECAL; MQ POWER, DCA25USI .......................... 3 ............ S/N 8011111 TO 8100219
28 M1561000004 DECAL; MQ POWER, DCA25USI .......................... 2 ............ S/N 8100220~
28 M1561000004 DECAL; MQ POWER, DCA25USI2 2
29 M1562100004 STRIPE 2
30 M1562100103 STRIPE; WHISPERWATT 2
31 M1562100204 STRIPE; 25 1
32 M1562100304 STRIPE; 25 1
33 M1562100404 STRIPE 2
34 M9510100304 DECAL; ENVIR. WARNING .................................... 1 ............ M91010030
35 0600500092 PLATE; MQ POWER 1
36 0021106016 MACHINE SCREW 4
37 M1550001404 DECAL; CAUTION 1
38 M9520000804 DECAL; AC, DCA25USIXF ..................................... 1 ............ M92000080 S/N 8101596~
38 M9520000804 DECAL; AC, DCA25USI2XF 1
39 M9510000104 DECAL; DOCUMENT BOX, DCA25USI2XF ........... 1 ............ M91000010
40 M1550001404 DECAL; CAUTION, DCA25USI2XF ........................ 1 ............ M15000120
41 M9521000004 DECAL; TERMINAL, DCA25USI2XF 1
42 M9504200004 DECAL; WARNING START FIRES, DCA25USI2XF 1 ............ M90420000 S/N 8103260~
NAMEPLATE AND DECALS ASSY.
