DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 89
DCA-25USI2XF— ENCLOSURE ASSY. (CONTINUED)
ENCLOSURE ASSY. (DCA25USI2XF ONLY)
NO. PART NO. PART NAME QTY. REMARKS
31 0016906016 HEX, HEAD BOLT 1
32 0207006000 HEX, NUT 2
33 0019208020 HEX, HEAD BOLT 4
34 M1443302203 REAR COVER 1
34A M1493305104 ACOUSTIC SHEET 1
35 M1443400103 DUCT 1
35A M1493305204 ACOUSTIC SHEET 1
36 0207006000 HEX, NUT 7
37 0019208020 HEX, HEAD BOLT 6
38 M1445200303 REAR DOOR 1
39 M1445600204 WINDOW PLATE 1
40 0207306000 HEX, NUT 10
40A 0041206000 WASHER, FLAT 10
41 M9113000002 DOOR HANDLE ASSY. 1
42 0021806016 MACHINE SCREW 4
42A 0030006000 HEX, NUT 4
43 M9112100404 HINGE 2
44 M9112100604 HINGE 2
45 0016908020 HEX, HEAD BOLT 8
46 M1463001902 ROOF PANEL 1
46A M1493505603 ACOUSTIC SHEET 1
47 0019208020 HEX, HEAD BOLT 23
48 M3310600004 COVER 1
49 0019208020 HEX, HEAD BOLT 4
50 M1453200802 SPLASHER PANEL 1
51 0016908020 HEX, HEAD BOLT 4
52 M1455100003 SIDE PANEL 1
52A M1493410104 ACOUSTIC SHEET 1
53 M1453004903 SIDE DOOR 1
53A M1493409904 ACOUSTIC SHEET 1
53B M1495501004 ACOUSTIC SHEET 1
54 M1455000803 SIDE DOOR 1
54A M1495501204 ACOUSTIC SHEET 1
54B M1495501304 ACOUSTIC SHEET 1
54C M1495401404 ACOUSTIC SHEET 1
55 M1453005003 SIDE DOOR 1
55A M1493410004 ACOUSTIC SHEET 1
56 M1455300403 DUCT 1
56A M1495401204 ACOUSTIC SHEET 3
56B M1495401404 ACOUSTIC SHEET 1
57 0207006000 HEX, NUT 6
DCA25USI2XF — ECLOSURE ASSY.
