DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 55
CONTROL BOX ASSY. (DCAUSIXF ONLY)
NO. PART NO. PART NAME QTY. REMARKS
1 M1215000612 CONTROL BOX 1
2 0601808820 CIRCUIT BREAKER, 3P 60A 1
3 0021005080 MACHINE SCREW 4
4 0601823240 RECTIFIER 2
5 0021004040 MACHINE SCREW 1
5A 0040004000 WASHER, LOCK 1
5B 0041204000 WASHER, FLAT 1
6 0601842384 RESISTOR, 20W 50 OHM 1
7 0027104010 MACHINE SCREW 2
8 0601815759 TERMINAL BOARD 1
8A M9521000004 DECAL; TERMINAL SYMBOL 1
9 0027104020 MACHINE SCREW 4
10 0601823863 RELAY UNIT 2
11 0027104016 MACHINE SCREW 4
12 0601820671 AUTOMATIC VOLTAGE REGULATOR 1
13 0027105016 MACHINE SCREW 4
14 0601806115 CURRENT TRANSFORMER, 50/5A 3
15 0027106016 MACHINE SCREW 6
16 0601820845 OVER CURRENT RELAY ....................................1 ............. S/N 8100001~8100586
16 0601820847 OVER CURRENT RELAY ....................................1 ............. S/N 8100587 AND ABOVE
17 0601820846 OVER CURRENT RELAY ....................................1 ............. S/N 8100001~8100586
17 0601820848 OVER CURRENT RELAY ....................................1 ............. S/N 8100587 AND ABOVE
18 0027104016 MACHINE SCREW 2
18A 0207004000 HEX, NUT 2
19 M1213500203 CONTROL BOX COVER 1
20 0016906016 HEX, HEAD BOLT 4
21 SELECTOR SWITCH ..........................................1 ............. S/N 8100001~8101735
............................................................................................ ORDER ITEMS W/#
21# M1270100104 SELECTOR SWITCH ..........................................1 ............. S/N 8101736 AND ABOVE
21A M1550002504 DECAL; SELECTOR SWITCH NUMBER ............................ S/N 8100001~8101735
21A# M1550002604 DECAL; SELECTOR SWITCH NUMBER ............................ S/N 8101736 AND ABOVE
22 M1215601204 SWITCH BRACKET ............................................1 ............. S/N 8100001~8101735
22# M1215600204 SWITCH BRACKET ............................................1 ............. S/N 8101736 AND ABOVE
23 0027103010 MACHINE SCREW ..............................................4 ............. S/N 8100001~8101735
23# 0027104030 MACHINE SCREW ..............................................4 ............. S/N 8101736 AND ABOVE
23A# 0207004000 HEX, NUT ............................................................4 ............. S/N 8101736 AND ABOVE
24 0016906016 HEX, HEAD BOLT 4
25 0330000160 EDGING ..............................................................1 ............. S/N 8100001~8101735
25# 0330000150 EDGING ..............................................................1 ............. S/N 8101736 AND ABOVE
26 M1215601104 SWITCH COVER .................................................1 ............. S/N 8100001~8101735
26# M1213600404 SWITCH COVER .................................................1 ............. S/N 8101736 AND ABOVE
26-1# 0228800060 RUBBER SEAL ...................................................1 ............. S/N 8101736 AND ABOVE
26-2# 0228800108 RUBBER SEAL ...................................................1 ............. S/N 8101736 AND ABOVE
26-3# 0317700180 RUBBER SEAL ...................................................1 ............. S/N 8101736 AND ABOVE
27 0016906016 HEX, HEAD BOLT ...............................................3 ............. S/N 8100001~8101735
27# 0016906016 HEX, HEAD BOLT ...............................................6 ............. S/N 8101736 ~AND ABOVE
DCA25USIXF — CONTROL BOX ASSY.
