DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 71
OUTPUT TERMINAL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M1230700003 TERMINAL PANEL 1
2 M9220000004 OUTPUT TERMINAL BOLT 5
3 M9220000104 TIE SCREW 5
4 0039308000 HEX, NUT 10
5 0040008000 WASHER, LOCK 15
6 0041408000 WASHER, FLAT 20
7 0016906025 HEX, HEAD BOLT 4
8 M1238100603 TERMINAL COVER ........................................ 1 ........... DCA25USI
8 M1236101103 TERMINAL COVER ........................................ 1 ........... DCA25USI2
9 M1238100704 OUTPUT WINDOW 1
10 0605010040 HINGE 2
11 0027103010 MACHINE SCREW 8
11A 0030003000 HEX, NUT 8
11B 0041203000 WASHER, FLAT 4
13 0016906020 HEX, HEAD BOLT 2
14 0016906016 HEX, HEAD BOLT 4
15 M1236400004 CABLE OUTLET COVER 1
16 M1236300004 SUPPORTER, CABLE OUTLET COVER 1
17 0016906020 HEX, HEAD BOLT 6
18 0601808803 CIRCUIT BREAKER, 1P@ 20A 2
19 0601808804 CIRCUIT BREAKER, 2P@50A 2
20 M1260700204 BREAKER FITTING COVER 1
20A 0222100115 CUSHION RUBBER 1
21 0016906020 HEX, HEAD BOLT 2
22 0601812598 RECEPTACLE,125V 20A X 2 (GFCI) 2
23 0601812538 RECEPTACLE ,CS6369 250V 50A 2
24 0027104018 MACHINE SCREW 8
24A 0207004000 HEX, NUT 8
25 M1238100503 TERMINAL COVER 1
26 0010112045 HEX, HEAD BOLT .......................................... 2 ........... DCA25USI
26 0010112040 HEX, HEAD BOLT .......................................... 2 ........... DCA25USI2
27 0041212000 WASHER, FLAT 2
28 M9310200004 STAY RUBBER 2
29 0030012000 HEX, NUT 2
30 M1236400104 COVER ........................................................... 1 ........... DCA25USI2
30A M1493408804 ACOUSTIC SHEET ........................................ 1 ........... DCA25USI2
31 0016906016 HEX, HEAD BOLT .......................................... 4 ........... DCA25USI2
OUTPUT TERMINAL ASSY.
