DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 85
ENCLOSURE ASSY. (DCA25USIXF ONLY)
NO. PART NO. PART NAME QTY. REMARKS
51 M9113000002 DOOR HANDLE ASSY. 2
51A C9312500004 SEAL RUBBER 2
52 0021806016 MACHINE SCREW 8
52A 0030006000 HEX, NUT 8
53 M9112100404 HINGE 4
54 M9112100504 HINGE 4
55 M9112100604 HINGE 8
56 0016908020 HEX, HEAD BOLT 32
57 0016908020 HEX, HEAD BOLT 2
60 M1435000903 BRACKET STAY 1
61 M1435000803 BRACKET STAY 1
62 0016908020 HEX, HEAD BOLT 4
63 M1435000703 SUPPORT LEG 1
63A M1498200004 ACOUSTIC SHEET 1
64 0016908020 HEX, HEAD BOLT 4
67 0016908020 HEX, HEAD BOLT 1
67A 0040508000 TOOTHED WASHER 1
68 0605503066 FUEL LEAK DETECTED SWITCH 1
69 M1414800204 BRACKET 1
70 0017108020 HEX, HEAD BOLT 2
71 M1423202103 FRONT LOUVER ............................................ 1 ........... S/N 8101466 AND ABOVE
72 0016906016 HEX, HEAD BOLT .......................................... 8 ........... S/N 8101466 AND ABOVE
DCA-25USIXF— ENCLOSURE ASSY. (CONTINUED) DCA25USIXF — ECLOSURE ASSY.
