DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 57
CONTROL BOX ASSY. (DCAUSIXF ONLY)
NO. PART NO. PART NAME QTY. REMARKS
28 0016906016 HEX, HEAD BOLT 9
28A 0040506000 TOOTHED WASHER 1
29 M1225000323 CONTROL PANEL ...............................................1 ............. S/N 8100001~8100586
29 M1225000333 CONTROL PANEL ...............................................1 ............. S/N 8100587 AND ABOVE
30 0601808985 FREQUENCY METER, 45~65Hz 240V 1
31 0601808985 AC AMMETER, 0~50A/100A:5A 1
32 0601801040 CHANGE-OVER SWITCH, AMMETER 1
33 0601806859 AC VOLTMETER, 0~600V 1
34 0601801041 CHANGE-OVER SWITCH, AMMETER 1
35 0601840073 RHEOSTAT(VR), 2W 1K OHM 1
36 0601840121 KNOB 1
37 8970444180 STARTER SWITCH .............................................1 ............. REPLACES P/N 0602100009
37A 8944024980 KEY, IGNITION SWITCH 1
38 0602103092 PREHEAT LAMP 1
38A 0601810245 BULB, DC18V 1
39 0602120095 TACHOMETER 1
40 0602122093 OIL PRESSURE GAUGE 1
41 0602123090 WATER TEMPERATURE GAUGE 1
42 0602121080 CHARGING AMMETER 1
43 0602125090 FUEL GAUGE 1
44 0602103092 ALARM LAMP 3
44A 0601810245 BULB, DC18V 3
45 9826800370 PANEL LIGHT ......................................................1 ............. REPLACES P/N 0601810141
46 0601831330 SWITCH, PANEL LIGHT 1
47 M1225100004 STOPPER 1
48 0027105010 MACHINE SCREW 2
49 0027105010 MACHINE SCREW 4
50 M9220100004 SET SCREW 2
51 0080200007 SNAP RING 2
52 8973259120 ENGINE CONTROLLER ......................................1 ............. REPLACES P/N 0602202523
53 0016906016 HEX, HEAD BOLT 2
53A 0207006000 HEX, NUT 2
54 5825500290 RELAY .................................................................2 ............. REPLACES P/N 0602201400
55 8942481610 GLOW RELAY .....................................................1 ............. REPLACES P/N 0602202502
56 0027105016 MACHINE SCREW 4
57 0602103092 ALARM LAMP .....................................................1 ............. S/N 8100231~ AND ABOVE
57A 0601810245 BULB, DC18V ......................................................1 ............. S/N 8100231~ AND ABOVE
58 M1213600305 SWITCH BRACKET ............................................1 ............. S/N 8101736 ~AND ABOVE
59 0027104016 MACHINE SCREW ..............................................4 ............. S/N 8101736 ~AND ABOVE
59A 0207004000 HEX, NUT ............................................................4 ............. S/N 8101736 ~AND ABOVE
60 M1248700004 WIRE HARNESS, GENERATOR .........................1 ............. S/N 8100001~8101735
60 M1248700024 WIRE HARNESS, GENERATOR .........................1 ............. S/N 8101736 ~AND ABOVE
61 M1359200602 WIRE HARNESS, ENGINE .................................1 ............. S/N 8100001 ~8101465
61 M1359200612 WIRE HARNESS, ENGINE .................................1 ............. S/N 8101466 ~ AND ABOVE
62 0601802160 FUSE, 5A 2
DCA25USIXF — CONTROL BOX ASSY.
