DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 83
ENCLOSURE ASSY. (DCA25USIXF ONLY)
NO. PART NO. PART NAME QTY. REMARKS
27 M1445300103 REAR COVER 1
27A M1495300504 ACOUSTIC SHEET 1
27B M1495300604 ACOUSTIC SHEET 1
28 M1445400103 DUCT 1
28A M1495300604 ACOUSTIC SHEET 2
29 0207006000 HEX, NUT 7
30 0019208020 HEX, HEAD BOLT 6
31 M1445200303 REAR DOOR 1
32 M1445600204 WINDOW PLATE 1
33 0207306000 HEX, NUT 10
33A 0041206000 WASHER, FLAT 10
34 M9113000002 DOOR HANDLE ASSY. 1
35 0021806016 MACHINE SCREW 4
35A 0030006000 HEX, NUT 4
36 M9112100404 HINGE 2
37 M9112100604 HINGE 2
38 0016908020 HEX, HEAD BOLT 8
39 M1463001402 ROOF PANEL 1
39A M1495500213 ACOUSTIC SHEET 1
40 0019208020 HEX, HEAD BOLT 23
41 M1465400104 COVER 1
42 0019208020 HEX, HEAD BOLT 2
43 M1455200702 SPLASHER PANEL 1
43A M1495401004 ACOUSTIC SHEET 1
44 0016908020 HEX, HEAD BOLT 4
45 M1455100003 SIDE PANEL 1
45A M1495400904 ACOUSTIC SHEET 1
46 M1455000903 SIDE DOOR 1
46A M1495500904 ACOUSTIC SHEET 1
46B M1495501004 ACOUSTIC SHEET 1
47 M1455000803 SIDE DOOR 1
47A M1495501204 ACOUSTIC SHEET 1
47B M1495501304 ACOUSTIC SHEET 1
46C M1495401304 ACOUSTIC SHEET 1
48 M1455000703 SIDE DOOR 1
48A M1495501104 ACOUSTIC SHEET 1
49 M1455300403 DUCT 1
49A M1495401204 ACOUSTIC SHEET 3
49B M1495401304 ACOUSTIC SHEET 1
49C M1495401404 ACOUSTIC SHEET 1
50 0207006000 HEX, NUT 6
DCA-25USIXF— ENCLOSURE ASSY. (CONTINUED) DCA25USIXF — ECLOSURE ASSY.
