PAGE 18 — DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11)
Figure 5. Major Components
Table 4. Generator Major Components
ITEM NO.
DESCRIPTION
1
Muffler Assembly
2
Engine Assembly
3
Generator Assembly
4
Output Terminal Assembly
5
Fuel Tank Assembly
6
Battery Assembly
7
Generator Control Panel Assembly
8
Engine Operating Panel Assembly
