DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 81
ENCLOSURE ASSY. (DCA25USIXF ONLY)
NO. PART NO. PART NAME QTY. REMARKS
1 M1413002502 BASE 1
1A M1493000004 ACOUSTIC SHEET 1
2 M1413100003 ENVIRONMENTAL TANK 1
3 0603306797 PLUG, 1-1/2 1
4 0016910030 HEX, HEAD BOLT 6
5 M1424000502 FRONT FRAME 1
5A M1495100403 ACOUSTIC SHEET 1
6 0601850151 GROMMET 1
7 M1424200702 FRONT DUCT 1
7A M1495100503 ACOUSTIC SHEET 1
8 0601851740 GROMMET 1
9 0601850239 GROMMET 1
10 0601850097 STOPPER 5
11 0027208025 MACHINE SCREW 5
12 0016908020 HEX, HEAD BOLT 9
13 0016906020 HEX, HEAD BOLT 4
14 0016908020 HEX, HEAD BOLT 6
15 M1425201204 DUCT COVER 2
16 0016906020 HEX, HEAD BOLT 10
17 M1424200803 HOSE COVER 1
18 0016906020 HEX, HEAD BOLT 4
19 M1425200903 COVER, FROM FRAME ................................. 1 ........... S/N 8100001~8101465
19 M1423202003 COVER, FROM FRAME ................................. 1 ........... S/N 8101466 AND ABOVE
20 0019208020 HEX, HEAD BOLT 5
21 M1435300503 CENTER FRAME 1
22 M1435300603 CENTER FRAME 1
23 0013612030 HEX, HEAD BOLT 4
23A 0040012000 WASHER, LOCK 4
24B 0041212000 WASHER, FLAT 4
24 0013612030 HEX, HEAD BOLT 4
24A 0040012000 WASHER, LOCK 4
24B 0041212000 WASHER, FLAT 4
25 M1445000802 REAR FRAME 1
25A M1495300304 ACOUSTIC SHEET 1
26 0016908020 HEX, HEAD BOLT 4
DCA25USIXF — ECLOSURE ASSY.
